IPX6 IEC60529 Waterproof Water Spray Test Equipment

Material:Stainless Steel And BrassIP Code:IPX5, IPX6
Standard:IEC60529Function:Ingress Protection Level Test
IPX5 Nozzle Diameter:Φ6.3mmIPX6 Nozzle Diameter:Φ12.5mm
IPX5 Flow:12.5±0.625(L/min)IPX6 Flow:100±5(L/min)
Controller:Touch Screen ControllerLoad Bearing:50KG
High Light:IPX5 Water Spray Test Equipment ,  CNAS IPX6 Water Spray Test Equipment ,  CNAS IEC60529 ip testing equipment

IEC60529 IPX5 IPX6 Waterproof Spray Test Chamber IP Test Machine


Water tank inside, cycling use of water

Conforms to the test distance for 2.5-3m

Sample electrifying test

Paint spraying, more beautiful

Main Technical Parameters:

ModelInternal dimensionOuter dimensionPower
IPX5 nozzle diameterΦ6.3mm
IPX6 nozzle diameterΦ12.5mm
IPX5 flow12.5±0.625(L/min)
IPX6 flow100±5(L/min)
load d-bearing50KG
Flow control modeManual adjustment (rotor flow meter)
Safety protection measuresLeakage protection, water shortage protection, short circuit protection

Note: other sizes can be customized according to requirements


It is used for the testing of IPX5 and IPX6

The device to shell protection grade (IP code) based mainly for electrical and electronic products, LED products, lamps,

electrical cabinets, communications, digital equipment, transportation and other products to simulate outdoor rain weather conditions,

and test the performance of the product is waterproof, to determine whether the corresponding level of protection,

in order to product’s design, development and test use.

Conform to:
IEC 60335-1

IP Code of the IPX5 and IPX6

Guangzhou Shice Equipment Co., Ltd. (hereinafter referred to as Guangzhou Shice) is the one professional focus on IEC testing equipments, IP waterproof testing equipments, electronic testing products and other testing products. Guangzhou Shice is professionally dedicated in providing laboratory testing equipment. We are now the high-tech enterprises with technical superiority and R & D capabilities in test instruments industry.

Guangzhou Shice are designed and manufactured as per the requirements of IEC, EN, UL, VDE, BS, AS, ISO standards and etc. Our main products are: waterproof and dustproof (IP) environmental test equipment; switch, plug, socket and coupler test equipment; mechanical strength impact test equipment; material fire hazard test equipment, enclosure protection test probes; household appliances safety test equipment; wire and cable test equipment; luminaires test equipment; electric tools test equipment. Our products are widely used in domestic and worldwide measurement & certification institutions, inspecting mechanism, laboratories, export & import inspection and quarantine bureau, various production companies and etc. Our customer includes Bureau Veritas, CSA, ITS, UL, TUV Rheinland, TUV SUD, SGS and etc.

More details:
